ENERGY SAVING OVERFLOW BALL MILL

Cylinder Diameter: 900mm~3600mm
Cylinder Length: 1200mm~6000mm
Overflow Type Ball Mill

Share This Product:

BRIGHT SPOT OF PRODUCT
MAIN PARAMETER PRODUCT
MORE

【Introduction】:

A overflow ball mill with rolling bearings, high efficiency and energy saving

【 Capacity 】:

Up to 160t/h

【Improvement】:

20-30%. Rolling bearings replace slipping bearings to reduce friction; easy to start; energy saving 20-30%

【Advantages】

The transmission machinery of Energy-saving overflow ball mill substitutes large-scale double row self-aligning roller bearing for sliding bearing, so it is easy to start and saves energy by 20-30%.

Energy-saving overflow ball mill adopts groove-type circular lining plate that is instrumental in increasing contact areas of iron balls and ores, which enhances grinding action and ore lifting capacity and decreases energy consumption.

Energy-saving overflow ball mill is configured with bigger discharge opening and has huge processing capacity.

Energy-saving overflow ball mill adopts whole milling house, which makes construction and installation easy.

Energy-saving overflow ball mill is equipped with oil-mist lubrication device which guarantees smooth operation of gears.

Model	Cylinder Diameter (mm)	Cylinder Length (mm)	Motor Model	Motor Power (kW)	Length (mm)	Width (mm)	Height (mm)	Capacity (t/h)	Effective Volume (m3)	Max. Ball Load (t)	Weight (kg)
MQYg 0912	900	1200	Y1800L-6	15	3666	1835	1400	0.25〜1.2	0.7	1	4265
MQYg 0918	900	1800	Y225M-8	22	4401	2535	2070	0.25〜1.6	0.9	1.66	5235
MQYg 1212	1200	1200	Y225S-8	18.5	3512	2076	1620	0.17 〜4.1	1.14	1.9	9610
MQYg 1224	1200	2400	Y280M-8	45	5745	2352	1778	0.26〜6.15	2.4	4.6	12219
MQYg 1240	1200	4000	JR117-8	80	7990	2412	1728	0.34 〜8.3	3.7	8	15940
MQYg 1515	1500	1500	Y280M-8	45	5740	3075	2280	1.4 〜4.5	2.2	4.2	17125
MQYg 1530	1500	3000	JR117-8	80	7253	3070	2280	2.8 〜9	5	10	21129
MQYg 1536	1500	3600	JR126-8	110	8595	3185	2280	2.8 〜10	5.4	10	23933
MQYg 1545	1500	4500	JR127-8	130	9680	3254	2370	3.5〜12.5	7	12	27500
MQYg 1557	1500	5700	JR127-8	130	10880	3254	2370	4.5 〜16	8.9	15	29359
MQYg 1836	1800	3620	JR136-8	180	8865	3683	2785	4.5 〜29	8.2	13.8	34970
MQYg 1845	1800	4520	JR137-8	210	9750	3683	2785	5〜33	10.2	19	37480
MQYg 1857	1830	5720	JR137-8	210	11009	3683	2785	6〜40	12.5	22	42096
MQYg 1863	1800	6320	JR138-8	320	11690	3781	2775	6〜45	14.2	25	45520.5
MQYg 1870	1800	7020	JR138-8	245	12599	3783	2735	7〜47	15	31.5	45136
MQYg 1875	1800	7520	JR138-8	245	12850	3783	2775	7.5 〜54	17	30	49450
MQYg 2122	2100	2200	JR128-8	155	7235	4120	3083	5〜29	6.6	20	35963
MQYg 2130	2100	3000	JR136-8	180	8220	4220	3083	6.5 〜36	9	27	40157
MQYg 2136	2100	3600	JR137-8	210	8958	4320	3025	7.5 〜42	10.8	23.5	44132.5
MQYg 2145	2100	4500	JR138-8	245	10350	4268	3121	10 〜45	13.5	23.6	42772
MQYg 2430	2400	3000	JR138-8	280	9023.5	4836.4	3490	7.2 〜92	11.5	22.5	57455.5
MQYg 2436	2400	3600	JR137-6	280	9623.5	4836.4	3490	8 〜110	13.8	25.5	60861.5
MQYg 2442	2400	4200	JR138-8	320	10204.5	4836.4	3440	8 〜130	16.5	31.5	63829.5
MQYg 2445	2400	4500	JR1510-8	380	11132.5	5091.4	4065	8.5 〜140	17.5	31	75923
MQYg 2460	2400	6000	JR1510-8	450	12623.5	5201.4	4060	9 〜180	23	40	83869
MQYg 2727	2700	2700	JR137-6	280	8901	4786.4	3620	7 〜110	13.8	29	66201
MQYg 2730	2700	3000	JR137-6	280	9201	4786.4	3620	8 〜115	15.3	32	72415
MQYg 2732	2700	3200	JR1410-8	320	10729	5000	3620	8〜120	15.7	32	83110
MQYg 2736	2700	3600	JR158-8	380	10764	5150	3620	12〜145	17.7	37	90441
MQYg 2740	2700	4000	JR1510-8	380	10870	5050	3620	12.5 〜152	19	40	93537
MQYg 2745	2700	4500	JR1510-8	380	11664	5150	3620	12.5 〜163	20.5	40	96196
MQYg 2747	2700	4700	JR1510-8	450	11864	5150	3620	13〜170	23	45	97605
MQYg 3231	3200	3100	TDMK630-36	630	12550	6750	5150	14〜180	21.4	45	112430
MQYg 3245	3200	4500	TDMK630-36	630	13950	7200	5152.5	95〜110	32.8	65	141629
MQYg 3660	3600	6000	TDMK1250-40	1250	19780	7700	5496	120〜200	55	102	193483
