- Capacity: 0.2~18t/h
- Liner material: Ceramic/Rubber
- Motor Power: 5.5~135kw
1.Transmission
Transmission is constituted by reduction box, transmission gear, electrical machine and electronic control, which its drive device can match up with energy consumption of grinding process that lower energy consumption.
2.Closed system
Ball mill and classifier constitute a negative pressure closed system that could reduce dust.
3.Ceramic lining plate
Stand wear and tear, shock resistance, high temperature resistance, acid and alkali resistant, anti-separation, easy to install and replace.
4.Ceramic media
Stand wear and tear, shock resistance, high temperature resistance, acid and alkali resistant, anti-separation, easy to install and replace.
|
Model
|
Loading weight
(ton/time) |
Rotate speed(r/min)
|
Power
（KW） |
Liner material
|
|
900×1200 |
0.2 |
38.5 |
5.5 |
Ceramics, silica, rubber and metal (according to the liner material and grinding materials determine the power) |
|
1300×1500 |
0.5 |
33 |
7.5 |
|
|
1500×1800 |
1.2 |
28.5 |
11 |
|
|
1800×2000 |
1.5 |
24 |
15 |
|
|
2600×2800 |
5 |
16.5 |
37 |
|
|
3000×3800 |
10 |
14.5 |
55 |
|
|
3200×4600 |
15 |
13.5 |
75 |
|
|
3400×6600 |
18 |
13 |
135 |
