- Feeding size: 175-241mm
- Processing capacity: 27-445t/h
- Applied material: river pebbles, rocks (limestone, granite, basalt, diabase, Andesite, etc.), ore ta
Mobile cone crusher is mainly composed of high efficient cone crusher, vibrating screen with perfect performance, belt conveyor, motor, controlling case and so on, which is applied in the industries of pharmaceutics, chemical, metallurgy, food and architecture.
1. Good mobility;
2. Compact structure, easy to use;
3. Cost savings, low cost;
4. Higher suitability;
5. Stable performance, easy maintenance;
6. Flexible configuration.
Material is evenly fed into the crusher by feeder, then be crushed by primary cone crusher, so as to realize circle crushing through closed system constituted by circular vibrating screen. Finished material will be transported through conveyor for continuous crushing.
|
Model |
VS3S185GYS300 |
VS3S216GYS400 |
VS3S216HP300 |
|
Transportation Length（mm） |
14500 |
15000 |
16000 |
|
Transportation Width（mm） |
3000 |
3000 |
4550 |
|
Transportation Height（mm） |
4400 |
4500 |
17000 |
|
Maximum Length（mm） |
17000 |
16000 |
4600 |
|
Maximum Width（mm） |
3400 |
3900 |
6900 |
|
Maximum Height（mm） |
5800 |
6500 |
4700 |
|
Weight（t） |
34.5 |
49.5 |
41 |
|
Tyre Configuration |
biax fitted |
triaxial fitted |
triaxial fitted |
|
Tire Configuration |
GYS300 |
GYS400 |
HP300 |
|
Feeding Belt Conveyor |
B650×15M×2 |
B800×15M×2 |
B800×15M×2 |
|
Discharging Belt Conveyor |
B650×14M |
B800×14M |
B800×16M |
|
Conveyor Belt for final products |
B500×15M |
B800×6M |
B650×15M×2 |
|
Under vibrating screen |
B800×7M |
B800×8M |
B800×9M |
|
Vibrating Screen Model |
3yk1854 |
3Yk2160 |
3Yk2160 |
