Technical Specifications
| 液压单钢轮压路机/Road Roller（8-14吨） | |||||
| MODEL | UNIT | VSRS208H | VSRS210H | VSRS212H | VSRS214H |
| Operating mass | Kg | 8000 | 10000 | 12000 | 14000 |
| Static linear load | N/cm | 230 | 286 | 286 | 326 |
| Vibrating amplitude | Mm | 0.4 | 1.6/0.8 | 1.6/0.8 | 1.7/0.8 |
| Vibrating frequency | Hz | 43 | 29/35 | 29/35 | 29/35 |
| Centrifugal force | KN | 70 | 260/160 | 260/160 | 290/180 |
| Travel speed | Km/h | 10 | 11 | 10.2 | 12 |
| Grade ability | % | 25 | 30 | 30 | 30 |
| Turning radius | mm | 6000 | 7000 | 7000 | 7000 |
| Overall dimension | mm | 5030×1880×2570 | 5610×2280×3000 | 5610×2280×3000 | 5900×2280×3050 |
| Vibration drum width | mm | 1700 | 2100 | 2100 | 2100 |
| Wheelbase | mm | 2684 | 3060 | 3060 | 3185 |
| Ground clearance | mm | 280 | 360 | 360 | 400 |
| Rated power | Kw | 75 | 110 | 110 | 110 |
| Diesel engine model | / | CUMMINS 4BT3.9 | CUMMINS 6BT5.9 | CUMMINS 6BT5.9 | CUMMINS 6BT5.9 |
| 液压单钢轮压路机/Road Roller （18-26吨） | |||||
| MODEL | UNIT | VSRS218H | VSRS220H | VSRS222H | VSRS226H |
| Operating mass | Kg | 18000 | 20000 | 22000 | 26000 |
| Static linear load | N/cm | 470 | 600 | 660 | 695 |
| Vibration amplitude | Mm | 1.9/0.95 | 1.9/0.95 | 1.9/0.95 | 1.9/0.95 |
| Vibration frequency | Hz | 28/35 | 28/35 | 28/35 | 28/35 |
| Centrifugal force | kN | 375/270 | 410/300 | 430/330 | 460/360 |
| Travel speed | km/h | 11 | 11 | 11 | 11 |
| Grade ability | % | 30 | 35 | 35 | 35 |
| Turning radius | mm | 7500 | 7500 | 7500 | 7500 |
| Overall dimension | mm | 6665*2280*3090 | 6665*2300*3090 | 6665*2340*3090 | 7025*2360*3090 |
| Vibration drum width | mm | 2100 | 2100 | 2100 | 2100 |
| Wheelbase | mm | 3380 | 3380 | 3380 | 3535 |
| Diesel engine model | / | 6BTA5.9 | 6BTA5.9 | 6BTA5.9 | 6CTA8.3 |
| Rated power | KW | 132 | 132 | 132 | 158 |
| 胶轮式压路机/Pneumatic Tire Roller （16-30吨） | |||||
| MODEL | UNIT | VSR1016P | VSR1016H | VSR2030P | VSR2030H |
| Max. operating mass | kg | 16000 | 16000 | 30000 | 30000 |
| Min. operating mass | kg | 10000 | 10000 | 20000 | 20000 |
| Max. Travel speed | km/h | 14.7 | 14 | 20.5 | 20.5 |
| Tire number (Front + Rear) | 5+6 | 5+6 | 5+6 | 5+6 | |
| Turning radius | mm | 7500 | 7500 | 8000 | 8000 |
| Rolling width | mm | 2280 | 2280 | 2790 | 2790 |
| Wheel base | mm | 3700 | 3700 | 3800 | 3800 |
| Gradeability | % | 30 | 30 | 20 | 20 |
| Diesel engine model | / | CUMMINS 4BT3.9 | CUMMINS 4BT3.9 | CUMMINS 6BTA5.9 | CUMMINS 6BTA5.9 |
| Rated power | kW | 75 | 75 | 125 | 125 |
| Rated speed | mm | 2300 | 2300 | 2300 | 2300 |
| Overall dimensions (with cabin) | mm | 4780x2100x3200 | 4780x2100x3200 | 4874x2790x3103 | 4874x2790x3103 |
