Main Dimension
| Main parameters | Unit | |
| Drilling | ||
| Maximum drilling diameter | mm | 3000 |
| Maximum drilling depth | m | 95/116 |
| Power head | ||
| Rated output torque | kN·m | 505 |
| rotational speed | rpm | 5~22 |
| Pressurization system | ||
| Apply pressure | kN | 420 |
| Pulling force | kN | 420 |
| wire rope diameter | mm | 32 |
| stroke | mm | 10000/21000 |
| Main hoist | ||
| lifting force | kN | 560 |
| wire rope diameter | mm | 40 |
| Maximum speed | m/min | 60 |
| Auxiliary hoist | ||
| lifting force | kN | 105 |
| wire rope diameter | mm | 20 |
| Maximum speed | m/min | 80 |
| Mast tilt angle | ||
| front/back | ° | 90/15 |
| left/right | ° | ±3 |
| Chassis | ||
| Engine Model | / | Volvo TAD1385VE |
| Engine power | kW/rpm | 405/1900 |
| emission | / | Chinese Ⅳ/EURO Ⅳ |
| Displacement | L | 12.78 |
| chassis unfolding width | mm | 4900 |
| track width | mm | 800 |
| Tail turning radius | mm | 4910 |
| Main unit | ||
| Height | mm | 30740 |
| Weight | t | 178 |
| Transport width | mm | 3600 |
| Transport height | mm | 3805 |
| Transport length | mm | 20550 |
| Drill pipe model | Weight (kg) | Drilling depth (m) |
| Ф580×3×20 | 19000 | 54 |
| Ф580×4×20 | 21200 | 72 |
| Ф580×4×21 | 22300 | 76 |
| Ф580×5×21 | 24800 | 95 |
| Ф580×6×20 | 22500 | 110 |
| Ф580×6×21 | 23600 | 116 |
