1.Central articulated frame, small turning radius, mobile and flexible, lateral stability, ease of operation in the narrow space.
2.Easy-to-read gauges display and ergonomically designed controls make the driving convenient and comfortable
3.Air over hydraulic disc brake on 4 wheels system and expire brake is used in brake system, which has large brake force and makes stable brake and high safety
4.Weichai Styer turbo-charged diesel engine is high power and torque, low fuel consumption and noise ,high reliability .Double-stage air filter is standard equipment for dusty fields.
5.Full hydraulic steering, power shift transmission, hydraulic control device work with two lightweight flexible operation, action smooth and reliable
6.Twin pump-merging flow of working pump and steering pump. when the machine is not steering more engine power is available to breakout and lift forces. Resulting in increased economy
7.
8.
Performance | 1 | rated load | 5000kg |
2 | overall weight | 16500kg | |
3 | rated bucket capacity | 3m3 | |
4 | maximum tractive force | 145KN | |
5 | maximum breakout force | 175KN | |
6 | maximum grade ability | 30 | |
7 | maximum dump height | 3142mm | |
8 | maximum dump reach | 1250mm | |
9 | overall dimension (LWH) | 808529653450mm | |
10 | minimum turning radius | 6732mm | |
Engine | 11 | model | Weichai Steyr WD10G220E23 |
12 | type | \\\ lnline water cooling dry cylinder injection | |
13 | -No. of cylinder-bore/stroke | 6126130mm | |
14 | rated power | 162kw--2000r/min | |
15 | maximum torque | 980N.m | |
16 | min fuel-consume ratio | 212.7g/kw.h | |
Transmission system | 17 | torque converter | Single stage two phase four components |
18 | gearbox mode | Power shift planetary structure | |
19 | gear shift | 21 2 forward shift 1 reverse shift | |
20 | maximum speed | 38km/h | |
Drive axles | 21 | main reducing spiral | bevel gear grade 1reduction |
22 | decelerating mode | planetary reduction,grade 1 | |
23 | wheel base (mm) | 3250mm | |
24 | wheel tread(mm) | 2250mm | |
25 | minimum ground clearance | 450mm | |
Hydraulic system | 26 | system working pressure | 18MPa |
27 | boom lifting time | 5.1s | |
28 | total time | 9.3s | |
29 | fuel tank capacity | 249L | |
30 | function of leveling automatically | yes | |
Brake system | 31 | service brake | air over hydraulic disc brake on 4 wheels |
32 | parking brake | manual parking brake | |
Tyre | 33 | type specification | 23.5-25 |
34 | front tyre pressure | 0.4Mpa | |
35 | rear tyre pressure | 0.35Mpa | |
36 | Fuel tank capacity | 290L |
