VSE130.8 EXCAVATOR
13-ton class crawler excavator, equipped with an 85 kW Cummins engine and a 0.53 m³ bucket capacity, suitable for various earthwork projects.
Email: info-vs@vostosun.com
Tel:+86-18964444930
Technical Specifications
| ENGINE | DIMENSION | ||
|---|---|---|---|
| Brand / model | Cummins / 4BTAA3.9 | A Overall length | 7580 mm |
| Type | 4-cycle, Water-cooled, Direct injection and turbocharged | B Overall width | 2490mm |
| Number (cylinders bore stroke) | 4 – 102 X 120 mm | C Overall height (to top of boom) | 2780 mm |
| Piston displacement | 3,9 L | D Overall height (to top of cab) | 2813 mm |
| Rating power | 86/2200 kw/rpm | E Counterweight ground clearance | 870 mm |
| Alternator | 24V 70A | F Min. ground clearance | 435 mm |
| Battery | 12V, 120 X 2 Ah | G Tail swing radius | 2015 mm |
| Max. torque | 460/1500 NM/rpm | H Track grounding length | 2750 mm |
| UNDERCARRIAGE | J Track length | 3486 mm | |
| Structure of chassis | structure X | K Track gauge | 1960 mm |
| Number of shoes | 42 each side | L Track width | 2460 mm |
| Number of carriers | 2 each side | M Track board width | 500 mm |
| Number of track rollers | 7 each side | N Turntable width | 2490 mm |
| HYDRAULICS | V Min swing radius | 2495 mm | |
| Hydraulic pump | Kawasaki / K3V63DT | W Max height at min swing radius | 6430 mm |
| Hydraulic pump / type | Variable displacement piston type | Maximum flow (l/m) | 128 L/min x 2 |
| Setting pressure | 34,3 Mpa (350 kg/cm2) | Z Height of counterweight | 1935 mm |
| Valve Type | Kayaba / KVMM160 | A1 Grounding length (in transportation) | 4410 mm |
| Control | full hydraulic joystick | Boom length | 4600 mm |
| Travel motor type | Kayaba / MAG-85VP Axial piston | Arm length | 2500 mm |
| Swing motor type | Kawasaki / M2X63 CHB Axial piston | WORKING RANGE | |
| HYDRAULIC CYLINDERS (Bore x Rod) | Operating weight | 13000 kg | |
| Boom | 2 - 105 × 70 mm | Standard type bucket | 0,53 m3 |
| Arm | 1 - 115 × 80 mm | O max. digging height | 8630 mm |
| Bucket | 1 - 95 × 65 mm | P max dumping height | 6180 mm |
| Swing speed | 12.6 rpm | Q max digging depth | 5500 mm |
| Travel speed | 3.1 ~ 5.3 km/h | R max vertical wall digging depth | 4940 mm |
| Max climbing degree | 35° | S max. digging depth (2.5m horizontal) | 5287 mm |
| Average group press | 38 Kpa | T max digging reach | 8305 mm |
| Bucket digging force | 80 KN | U max digging reach at ground level | 8180 mm |
