1. Compact structure, maneuverable movement suitable for narrow space operation
2. Open cabin with mechanical control system
3. Double accelerograph control
4. Multi-function with a wide range of attachments
5. Hydraulic break
| VSSL1050 |
Rated operating capacity (kg) | 1050 |
Tipping load (kg) | 2100 |
Bucket capacity (m3) | 0.6 |
Operating weight (kg) | 3500 |
Max. travel speed (km/h) | 12/18 |
Hydraulic pump flow (L/min) | 75/125 |
Fuel tank capacity (L) | 60/90 |
Overall length (mm) | 3560 |
Overall width (mm) | 1900 |
Overall height (mm) | 2050 |
Height at maximum extension (mm) | 4070 |
Height to bucket hinge pin (mm) | 3150 |
Width with bucket (mm) | 1900 |
Track width (mm) | 1500 |
Wheelbase (mm) | 1185 |
Ground clearance (mm) | 200 |
Dump angle (°) | 40 |
Dumping height (mm) | 2450 |
Engine model | Deutz D226B |
Net power (hp/ rpm) | 75/2500 |
Displacement (L) | 3.9 |
All daily maintenance can be completed when open the forward cover. The cabin can be turned rear in large-angle.
All instruments and operating buttons are within the reach of the operator.
CE certification keep high quality control.
Chinese XINCHAI engine famous in China，economic and easy get spare parts in your country. PERKINS engine is available.
enlarged water tank in order to heat faster.
International standard quick coupler fits various attachments in the world.
Italy Bondioli & Pavesi Multi-valve.
Italy FAST quick fitting and all hydraulic hose with sleeve protection.
Operators may enjoy the Proportional controlled pilot joystick by getting familiar with the machine quickly with less fatigue.
The cab gets lots of space and good view. It is in line with ROPS regulation.
US EATON hydraulic motor keep high power and long life.
US SAUER Traveling hydraulic system adopts closed loop circuit with features of compact structure, good maneuverability and lower heat emission.
When lifting the boom, the bucket automatically keeps levelling.
