1. Compact structure, maneuverable movement suitable for narrow space operation
2. Open cabin with mechanical control system
3. Double accelerograph control
4. Multi-function with a wide range of attachments
5. Hydraulic break
| Item | Details |
|---|---|
| Rated Operating Capacity | 1000 kg |
| Tipping Load | 2000 kg |
| Bucket Capacity | 0.5 m³ |
| Operating Weight | 4000 kg |
| Max. Travel Speed | 12 / 18 km/h |
| Hydraulic Pump Flow | 75 L/min |
| Fuel Tank Capacity | 80 L |
| Overall Dimensions | 3500 × 1830 × 2015 mm |
| Height at Maximum Extension | 3480 mm |
| Height to Bucket Hinge Pin | 2900 mm |
| Width with Bucket | 1850 mm |
| Crawler Width | 320 mm |
| Crawler on Ground Length | 1500 mm |
| Ground Clearance | 200 mm |
| Engine Maker / Model | 498 / Cummins / Perkins (optional) |
| Net Power | 75 hp / 2500 rpm |
| Engine Type | 4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine |
| Displacement | 3.9 L |
| Standard Configuration | Open-type operator cab Hydraulic joystick controls Standard bucket Auxiliary hydraulic couplers |
All daily maintenance can be completed when open the forward cover. The cabin can be turned rear in large-angle.
All instruments and operating buttons are within the reach of the operator.
CE certification keep high quality control.
Chinese XINCHAI engine famous in Chinaeconomic and easy get spare parts in your country. PERKINS and Cummins engine is available.
enlarged water tank in order to heat faster.
International standard quick coupler fits various attachments in the world.
Italy Bondioli & Pavesi Multi-valve.
Italy FAST quick fitting and all hydraulic hose with sleeve protection.
Operators may enjoy the Proportional controlled pilot joystick by getting familiar with the machine quickly with less fatigue.
The cab gets lots of space and good view. It is in line with ROPS regulation.
US EATON hydraulic motor keep high power and long life.
US SAUER Traveling hydraulic system adopts closed loop circuit with features of compact structure, good maneuverability and lower heat emission.
When lifting the boom, the bucket automatically keeps levelling.
